1U4G-ROME

$3,726.00

ADD TO CART

OVERVIEW

ASRock 1U 8Bays Single AMD Processor Rackmount Server

1U Rackmount with 1+1 Platinum 2000W CRPS
Single Socket SP3 (LGA 4094), supports AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology)/7002 series Processors
8x DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, RDIMM/LRDIMM-3DS
4x FH dual-slot PCIe4.0 x16, 2x low-profile PCIe4.0 x16
8x E1.S/ M.2 (PCIe x4) trays
2x RJ45 (1GbE) by Intel® i350-AM2
Remote Management (IPMI)

Storage configuration notice:
Hot-swap:
8x E1.S (PCIe x4) trays

SPECIFICATIONS

SKU

1U4G-ROME

Processor

CPU:
Supports AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology)/7002 Series Processors
A BIOS update is required to support AMD EPYC™ 7003 series processors with AMD 3D V-Cache™ Technology
Socket:
SP3
Chipset:
System on chip

Memory

Supported DIMM Quantity:
8x DDR4 288-pin DIMM slots (1DPC)
Supported Type:
DDR4 R DIMM/ LR DIMM
Max. Capacity per DIMM:
RDIMM: 64GB, 32GB, 16GB, 8GB
LRDIMM: 256GB, 128GB, 64GB
256GB is to be validated
Max. DIMM Frequency:
RDIMM: 3200/2933/2666/2400MHz
LRDIMM: 3200/2933/2666/2400MHz
Voltage:
1.2V

Chassis

1U Rackmount Chassis

Dimensions

438mmx 880mmx 43.5mm (without ear)

17.2"x 34.6"x 1.7"

Front Panel

Buttons:
UID, Power, Reset
LEDs:
System Fail, Power, LAN1, LAN2
I/O Ports:
1x Type-A (USB3.2 Gen1)

Bios	BIOS Type: 32MB AMI UEFI Legal BIOS

Onboard Devices

Ethernet
Additional GbE Controller:
Intel® i350-AM2: 2 (1GbE) RJ45

Graphics
Controller:
ASPEED BMC AST2500:
1 DB15 (VGA)

HDD Drive Bays

Front Side Drive Bay:
8x E1.S (PCIe x4) trays
support up to 8.01mm thickness E1.S or 22110/2280 M.2 (PCIe x4) by optional ED_M2W_G4 adapter card
Internal Side:
2 header (9-pin, USB2.0) support USB DOM

Expansion Slots

PCIe x 16
Front:
supports 3 FH dual-slot* PCIe4.0 x16 via 1U4G_SL2P_L_RDV and 1U4G_SL2P_R_RDV
Rear:
supports 1 FH dual-slot* PCIe4.0 x16 via 1U4G_SL2P_L_RDV
supports 2 low-profile PCIe4.0 x16 via RB1UX16_G4
Active-cooled cards and cards with power connector on the top edge are not supported.

Power Supply

Type:
1+1 CRPS
Output Watts:
2000W
Efficiency:
80-PLUS Platinum
AC Input:
200-240V, 50/60Hz

Input Output

VGA Port:
1x DB15 (VGA)
USB 3.2 Gen1 Port:
2x Type-A (USB3.2 Gen1)
RJ45:
2x RJ45 (1GbE) via i350-AM2
1x dedicated IPMI

Cooling

8x dual-rotor hot-swap 40x56 mm fans

Operating Environment

Temperature:
Operation temperature: 10°C ~ 35°C* / Non operation temperature: -40°C ~ 70°C
Please contact Sales for the operating temperature while GPGPU deployed
Humidity:
Non operation humidity: 20% ~ 90% ( Non condensing)

PHOTOS

1U4G-ROME

MY CONFIGURATION

CPU

AMD EPYC 3rd Gen MILAN 7543P 32 Core 2.80GHz

+ $1,977.00

AMD EPYC 3rd Gen MILAN 72F3 8 Core 3.70GHz

+ $1,662.00

AMD EPYC 3rd Gen MILAN 7313 16 Core 3.00GHz

Added

AMD EPYC 3rd Gen MILAN 7313P 16 Core 3.00GHz

- $205.00

AMD EPYC 3rd Gen MILAN 7343 16 Core 3.20GHz

+ $578.00

AMD EPYC 3rd Gen MILAN 7453 28 Core 2.75GHz

+ $584.00

AMD EPYC 3rd Gen MILAN 73F3 16 Core 3.50GHz

+ $2,925.00

AMD EPYC 3rd Gen MILAN 7443P 24 Core 2.85GHz

+ $305.00

AMD EPYC 3rd Gen MILAN 7413 24 Core 2.65GHz

+ $2,695.00

AMD EPYC 3rd Gen MILAN 7443 24 Core 2.85GHz

+ $1,113.00

AMD EPYC 3rd Gen MILAN 7643 48 Core 2.30GHz

+ $4,694.00

AMD EPYC 3rd Gen MILAN 7543 32 Core 2.80GHz

+ $3,214.00

AMD EPYC 3rd Gen MILAN 74F3 24 Core 3.20GHz

+ $2,180.00

AMD EPYC 3rd Gen MILAN 7513 32 Core 2.60GHz

+ $2,108.00

AMD EPYC 3rd Gen MILAN 7713 64 Core 2.00GHz

+ $7,173.00

AMD EPYC 3rd Gen MILAN 7663 56 Core 2.00GHz

+ $6,340.00

AMD EPYC 3rd Gen MILAN 7763 64 Core 2.45GHz

+ $8,168.00

AMD EPYC 3rd Gen MILAN 7713P 64 Core 2.00GHz

+ $4,713.00

AMD EPYC 3rd Gen MILAN 75F3 32 Core 2.95GHz

+ $4,533.00

MEMORY

Samsung 8GB DDR4 3200 ECC RDIMM Memory

Added

Samsung 64GB DDR4 3200 ECC RDIMM Memory

+ $416.00

Samsung 32GB DDR4 3200 ECC RDIMM Memory

+ $168.00

Samsung 16GB DDR4 3200 ECC RDIMM Memory

+ $62.00

Samsung 32GB DDR4 2933 ECC RDIMM Memory

+ $162.00

Samsung 16GB DDR4 2933 ECC RDIMM Memory

+ $56.00

Samsung 8GB DDR4 2933 ECC RDIMM Memory

- $6.00

Samsung 64GB DDR4 2933 ECC RDIMM Memory

+ $410.00

Hynix 64GB DDR4 2666 ECC LRDIMM Memory

+ $456.00

Samsung 128GB DDR4 3200 ECC LRDIMM Memory

+ $1,424.00

Samsung 64GB DDR4 2933 ECC LRDIMM Memory

+ $484.00

Enterprise-Class HDD/SSD

NETWORK CARD

Mellanox NVIDIA 200GbE MCX653105A-HDAT-SP ConnectX-6 VPI Ethernet Adapter (1x QSFP56)

+ $1,976.00

Broadcom NetXtreme 100G PCIe 4.0 x16 EthernetCard (2x QSFP56)

+ $1,279.00

Broadcom NetXtreme 50G PCIe 3.0 x8 Ethernet Card (1x QSFP28)

+ $508.00

Broadcom NetXtreme 25G PCIe 4.0 x16 Ethernet Card (4x SFP28)

+ $689.00

Broadcom NetXtreme 10G PCIe 3.0 x8 Ethernet Card (2x RJ45)

+ $363.00

Broadcom NetXtreme 25G PCIe 3.0 x8 Ethernet Card (2x SFP28)

+ $271.00

Broadcom NetXtreme 10G PCIe 3.0 x8 Ethernet Card (2x SFP+)

+ $289.00

Broadcom NetXtreme 1G PCIe 2.0 x4 Ethernet Card (4x RJ45)

+ $123.00

Broadcom NetXtreme 1G PCIe 2.0 x1 Ethernet Card (2x RJ45)

+ $96.00

Mellanox NVIDIA 200GbE MCX653106A-HDAT-SP ConnectX-6 VPI Ethernet Adapter (2x QSFP56)

+ $2,145.00

Mellanox NVIDIA 100GbE MCX516A-CCAT ConnectX-5 Ethernet Adapter (2x QSFP28)

+ $1,664.00

Mellanox NVIDIA 10/25GbE MCX512A-ACAT ConnectX-5 Ethernet Adapter (2x QSFP28)

+ $610.00

*Please contact our sales rep for special requirements

Added

Intel® 25G Ethernet Adapter XXV710-DA1 (1x SFP28)

+ $475.00

Intel® 10G Ethernet Adapter X520-DA2 (2x SFP+)

+ $377.00

Intel® 25G Ethernet Adapter XXV710-DA2 (2x SFP28)

+ $512.00

Intel® 40G Ethernet Adapter XL710-QDA2 (2x QSFP+)

+ $636.00

Intel® 10G Ethernet Adapter X550-T2 (2x RJ45)

+ $462.00

Intel® 10G Ethernet Adapter X550-T1 (1x RJ45)

+ $428.00

Intel® 1G Ethernet Adapter I350-T4V2 (4x RJ-45)

+ $341.00

Intel® 1G Ethernet Adapter I350-T2V2 (2x RJ-45)

+ $241.00

Intel® 10G Ethernet Adapter X710-DA2 (2x QSFP+)

+ $501.00

Intel® 40G Ethernet Adapter XL710-QDA1 (1x QSFP+)

+ $558.00

OPERATING SYSTEM

*Please contact our sales for more operating system options

Added

Debian Linux (No Media) (32-Bit/64-Bit)

+ $99.00

Fedora Linux Desktop Edition (No Media) (32-Bit/64-Bit)

+ $99.00

Ubuntu Linux LTS Server Edition (No Media) (32-Bit/64-Bit)

+ $99.00

Fedora Linux Workstation Edition 64-bit (No Media)

+ $99.00

CentOS Enterprise Linux (No Media) (32-Bit/64-bit)

+ $99.00

Microsoft Windows Server 2022 Standard 64-bit-1User

+ $799.00

WARRANTY

*1 Year Parts Replacement Warranty

Added

3 Year Parts Replacement Warranty - Server Value $500 to $2000

+ $299.00

3 Year Parts Replacement Warranty - Server Value $2001 to $4000

+ $399.00

3 Year Parts Replacement Warranty - Server Value $4001 to $7000

+ $599.00

3 Year Parts Replacement Warranty - Server Value $7001 to $10000

+ $899.00

3 Year Parts Replacement Warranty - Server Value Over $10000

+ $1,280.00

$3,726.00	ADD TO CART
