R183-Z90-AAD1

Please Inquire

Gigabyte 1U 4Bays Dual AMD Processor Rackmount Server

AMD EPYC™ 9004 series processor family
Dual processor, 5nm technology
12-Channel RDIMM DDR5, 24x DIMMs
Dual ROM Architecture supported
2x 1Gb/s LAN ports (Intel® I350-AM2)
1x dedicated management port
4x 3.5/2.5" Gen4 NVMe/SATA hot-swappable bays
3x Ultra-Fast M.2 with PCIe Gen3 interface
2x FHHL PCIe Gen5x16 expansion slots
2x OCP 3.0 Gen5x16 mezzanine slots
Dual 1600W (240V) 80 PLUS Platinum redundant power supply

Storage configuration notice:
External:
4x 3.5" Hot-swap HDD Bays
M.2:
1x M.2

SKU	R183-Z90-AAD1

Processor

AMD EPYC™ 9004 series processor family
Dual processor, 5nm technology
Up to 96-core, 192 threads per processor
cTDP up to 300W

Supports CPU 400W, OCP 3.0 ≦21W at ambient 30°C
Socket
2 x LGA 6096
Socket SP5

Memory

24 x DIMM slots
DDR5 memory supported only
12-Channel memory architecture per processor
RDIMM modules up to 128GB supported
3DS RDIMM modules up to 256GB supported
Memory speed: Up to 4800 MHz

Chassis

1U Rackmount Chassis

Dimensions

438mm x 43.5mm x 815mm

Onboard Devices

LAN
2x 1GbE LAN ports (1x Intel® I350-AM2)
Supported NCSI function
1x 10/100/1000 management LAN

Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM

HDD Drive Bays

4x 3.5/2.5" Gen4 NVMe/SATA/SAS hot-swappable bays

SAS card is required for SAS devices support

SAS
Depends on SAS Add-on card

Expansion Slots

Riser Card CRS101T:
1x PCIex16 slot (Gen5x16), FHHL from CPU_0

Riser Card CRS101Q:
1x PCIex16 slot (Gen5x16), FHHL from CPU_1

2x OCP 3.0 slots with PCIe Gen5x16 bandwidth
( 1x from CPU_0 and 1x from CPU_1)
Supported NCSI function

1x M.2 slot:
M-key
PCIe Gen3x4 from CPU_0
Supports 2280/22110 cards

1x M.2 slot:
M-key
PCIe Gen3x4 from CPU_1
Supports 2280/22110 cards

1x M.2 slot:
M-key
PCIe Gen3x2 from CPU_1
Supports 2280/22110 cards

Power Supply

Dual 1600W (240V) 80 PLUS Platinum redundant power supply

AC Input:
100-120V~/ 12A, 50-60Hz
200-240V~/ 10A, 50-60Hz

DC Input:
240Vdc/ 10A

DC Output:
Max 1000W/ 100-120V~
+ 12V/ 81.5A
+ 12Vsb/ 2.5A
Max 1600W/ 200-240V~ or 240Vdc Input
+ 12V/ 133A
+ 12Vsb/ 2.5A

Input Output

Internal I/O
3x M.2 slots
1x TPM header
2x OCP 3.0 mezzanine slots

Front I/O
2x USB 3.2 Gen1
1x Power button with LED
1x ID button with LED
1x NMI button
1x Reset button
2x LAN activity LEDs
1x HDD activity LED
1x System status LED

Rear I/O
2x USB 3.2 Gen1
1x Mini-DP
2x RJ45
1x MLAN
1x ID button with LED

Backplane I/O
Backplane P/N: 9CBP1047NR-00
Speed and bandwidth:
PCIe Gen4x4 or SATA 6Gb/s or SAS 12Gb/s

Cooling

8x 40x40x56mm (32,000rpm) System Fans

Operating Environment

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Details

System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
