1 x M.2 (2230), E-key (Wi-Fi), PCIe Gen2 x1, from ConnectX-8
Power Supply
Single 1600W ATX 80 PLUS Gold power supply
The system power supply requires C19 power cord.
Note:
220-240V AC input is recommended for optimized user experience.
Input Output
Front I/O:
1x USB 3.2 Gen2 port (Type-C)
2x USB 3.2 Gen1 ports (Type-A)
2x Audio jacks (Audio out/Mic)
1x Power button with LED
1x Reset button with storage activity LED
Rear I/O:
4x USB 3.2 Gen2 ports (Type-A)
1x Micro USB port (USB-to-UART)
1x Mini-DP
2x QSFP ports
1x RJ45 port
1x MLAN port
2x Wi-Fi antenna ports
3x Audio jacks (Audio in/Audio out/Mic)
Cooling
System Fans:
3x 120x120x25mm
Operating Environment
Operating temperature: 10°C to 35°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Note:
To ensure system stability and prevent condensation, when the relative humidity exceeds 50%, the coolant inlet temperature must be higher than the dry-bulb temperature and it should not exceed 45°C.
