B684-A80-AAS1

Please Inquire

Gigabyte 6U 10Nodes 20Bays AMD Processor Blade Server

6U 10-node front access server system
Dual Intel® Xeon® 6900E+/6900-Series Processors per node
12-Channel DDR5 RDIMM/MRDIMM per CPU with 24 x DIMMs per node
2x E3.S Gen5 NVMe hot-swap bays per node
3x LP PCIe x16 slots with Gen5 x16 lanes per node
7+3 3200 W 80 PLUS Titanium redundant power supplies

Storage configuration notice:
External:
2x E3.S NVMe drive bays per node

SKU	B684-A80-AAS1

Processor

CPU

Intel® Xeon® 6+ Processors
Intel® Xeon® 6900E+ Processors

Intel® Xeon® 6 Processors
Intel® Xeon® 6900-Series Processors

Dual processors per node, TDP up to 500 W

Note:
If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Socket
20x LGA 7529
Socket BR

Memory

24x DIMM slots per node
Support DDR5 RDIMM/MRDIMM
12-Channel memory per processor

Intel Xeon 6900E+:
RDIMM: Up to 8000 MT/s

Intel Xeon 6900-series:
RDIMM: Up to 6400 MT/s
MRDIMM: Up to 8800 MT/s

Note:
MRDIMMs are supported only on select Intel® Xeon® 6 processors with P-cores.

Chassis

6U Chassis

Dimensions

WxHxD
447mm x 262.3mm x 900mm

Onboard Devices

LAN
Front:
1x 10/100/1000 Mb/s Management LAN per node

Rear (MLAN board):
2x Chassis Management LAN

Spanning Tree Protocol (STP) must be enabled on LAN switches when using a ring topology.

Video
Integrated in ASPEED® AST2600
1x Mini-DP per node

HDD Drive Bays

Front hot-swap:
2x E3.S Gen5 NVMe per node, from CPU_0

Expansion Slots

Riser Card x 3:
2x LP x16 (Gen5 x16) per node, from CPU_0
1x LP x16 (Gen5 x16) per node, from CPU_1

Note：
Supports ambient temperatures up to 25°C with all three PCIe slots occupied.

Power Supply

7+3 3200 W 80 PLUS Titanium redundant power supplies

AC Input:
100-127V~/ 16A, 50-60Hz
200-220V~/ 16A, 50-60Hz
220-240V~/ 16A, 50-60Hz

DC Input: (Only for China)
240Vdc/ 16A

DC Output:
Max 1300W/ 100-127V~
+12.2V/ 106.6A
+12.2Vsb/ 3A

Max 3000W/ 200-220V~
+12.2V/ 246A
+12.2Vsb/ 3A

Max 3200W/ 220-240V~ or 240Vdc Input
+12.2V/ 262.3A
+12.2Vsb/ 3A

Note：
The system power supply requires C19 power cord.

Input Output

Front I/O
Per node:
2x USB 3.2 Gen1 ports (Type-A)
1x Mini-DP
1x MLAN port
1x Power button with LED
1x System status LED
1x ID LED

Rear I/O
MLAN board:
2x CMC ports
1x CMC status LED

Cooling

System Fans
10x 80x80x80mm

Operating Environment

Operating temperature: 10°C to 30°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)

PHOTOS

MY CONFIGURATION

CPU

Intel® Xeon® 6900E+ Series Processor 6990E+ (2.20 GHz 450W)

Intel® Xeon® 6900E+ Series Processor 6960E+ (2.40 GHz 330W)

Added

Intel® Xeon® 6900E+ Series Processor 6970E+ (2.30 GHz 400W)

Intel® Xeon® 6900E+ Series Processor 6980E+ (2.10 GHz 400W)

MEMORY

Samsung 64GB DDR5 6400MHz ECC RDIMM Memory

Samsung 32GB DDR5 6400MHz ECC RDIMM Memory

Added

Samsung 96GB DDR5 6400MHz ECC RDIMM Memory

Enterprise-Class HDD/SSD

Samsung PM1743 NVME E3.S SSD 15.36TB

Samsung PM1743 NVME E3.S SSD 3.84TB

Samsung PM1743 NVME E3.S SSD 1.92TB

Added

Samsung PM1743 NVME E3.S SSD 7.68TB

OPERATING SYSTEM

*Please contact our sales for more operating system options

Added

Fedora Linux Workstation Edition 64-bit (No Media)

Fedora Linux Desktop Edition (No Media) (32-Bit/64-Bit)

Ubuntu Linux LTS Server Edition (No Media) (32-Bit/64-Bit)

Debian Linux (No Media) (32-Bit/64-Bit)

CentOS Enterprise Linux (No Media) (32-Bit/64-bit)

Microsoft Windows Server 2025 Standard 64-bit-1User

WARRANTY

*1 Year Parts Replacement Warranty

Added

3 Year Parts Replacement Warranty - Server Value $500 to $2000

3 Year Parts Replacement Warranty - Server Value $2001 to $4000

3 Year Parts Replacement Warranty - Server Value $4001 to $7000

3 Year Parts Replacement Warranty - Server Value $7001 to $10000

3 Year Parts Replacement Warranty - Server Value Over $10000

Please Inquire
	ADD TO QUOTE
