Gigabyte 2U 4Bays Dual Processor Rackmount Server

Gigabyte 2U 4Bays Dual Processor Rackmount Server

5th Gen Intel® Xeon® Scalable Processors
4th Gen Intel® Xeon® Scalable Processors
Intel® Xeon® CPU Max Series
Dual processor, LGA 4677
8-Channel RDIMM DDR5 per processor, 32 x DIMMs
Dual ROM Architecture
2 x 1Gb/s LAN ports (Intel® I350-AM2)
1 x Dedicated management port
4 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays on rear side
6 x FHHL PCIe Gen5 x16 slots
2 x OCP 3.0 Gen5 x16 slots
Dual 1600W 80 PLUS Platinum redundant power supply

Storage configuration notice:
External:
rear 4x 2.5" Hot-swap HDD Bays

Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.

SKU	E283-S90-AAD1
Processor	5th Generation Intel® Xeon® Scalable Processors 4th Generation Intel® Xeon® Scalable Processors Intel® Xeon® CPU Max Series Dual processor, CPU TDP up to 350W NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable Socket 2 x LGA 4677 Socket E
Memory	32 x DIMM slots DDR5 memory supported only 8-Channel memory architecture RDIMM modules up to 96GB supported 3DS RDIMM modules up to 256GB supported 5th Gen Intel® Xeon®: Up to 5600MHz (1DPC), 4400MHz (2DPC) 4th Gen Intel® Xeon®: Up to 4800MHz (1DPC), 4400MHz (2DPC) Intel® Xeon® Max Series: Up to 4800MHz (1DPC), 4400MHz (2DPC) Note: 5600MHz support under 2DPC configuration requires verified memory and BIOS setup.
Chassis	2U Rackmount Chassis
Dimensions	438mm x 87.5mm x 625mm
Onboard Devices	LAN 2 x 1Gb/s LAN ports (1 x Intel® I350-AM2) Support NCSI function 1 x 10/100/1000 management LAN Video Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp, DDR4 SDRAM
HDD Drive Bays	Rear side: 4 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays SAS card is required for SAS devices support
Expansion Slots	Riser Card CRS101J: 1x PCIex16 (Gen5x16) FHHL slot, from CPU_0 Riser Card CRS101K: 1x PCIex16 (Gen5x16) FHHL slot, from CPU_1 Riser Card CRS202G: 2x PCIex16 (Gen5x16) FHHL slots, from CPU_0* NOTE: Slot_10 would be downgraded to Gen4 if usingxCC CPU with 4x UPI Riser Card CRS202H: 2x PCIex16 (Gen5x16) FHHL slots, from CPU_1 1x OCP 3.0 slot with PCIe Gen5x16 bandwidth, from CPU_0 Supports NCSI function 1x OCP 3.0 slot with PCIe Gen5x16 bandwidth, from CPU_1 Supports NCSI function
Power Supply	Dual 1600W (240V) 80 PLUS Platinum redundant power supply AC Input: 100-120V~/ 12A, 50-60Hz 200-240V~/ 10A, 50-60Hz DC Input: 240Vdc/ 10A DC Output: Max 1000W/ 100-120V~ + 12V/ 81.5A + 12Vsb/ 2.5A Max 1600W/ 200-240V~ or 240Vdc Input + 12V/ 133A + 12Vsb/ 2.5A
Input Output	Internal I/O 1x TPM header 1x VROC connector 2x OCP 3.0 mezzanine slots Front I/O 2x USB 3.2 Gen1 1x Power button with LED 1x ID button with LED 1x NMI button 1x Reset button 2x LAN activity LEDs 1x HDD activity LED 1x System status LED Rear I/O 2x USB 3.2 Gen1 1x Mini-DP 2x RJ45 1x MLAN 1x ID button with LED Backplane I/O Backplane P/N: 9CBP2022NR-00 Speed and bandwidth: PCIe Gen4x4 or SATA 6Gb/s or SAS 12Gb/s
Cooling	4 x 80x80x38mm (18,300rpm) System Fans
Operating Environment	Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing)
Details	System Management Aspeed® AST2600 management controller GIGABYTE Management Console (AMI MegaRAC SP-X) web interface Dashboard HTML5 KVM Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.) Sensor Reading History Data FRU Information SEL Log in Linear Storage / Circular Storage Policy Hardware Inventory Fan Profile System Firewall Power Consumption Power Control LDAP / AD / RADIUS Support Backup & Restore Configuration Remote BIOS/BMC/CPLD Update Event Log Filter User Management Media Redirection Settings PAM Order Settings SSL Settings SMTP Settings
